2016 Polaris ACE

SOLD

Your Price: $5,299

580 people have recently viewed it.
Request More Info

The smallest ACE is powered by 325cc, liquid cooled double overhead cam engine. It is easy to drive and compact enough to fit on the tightest trails that even a 50-inch wide UTV can’t go down. For suspension, Polaris used their tried and true and very stable MacPherson Stut front end and dual A-arms out back.

  • Status:
    Pre-Owned
  • Vehicle:
    2016 Polaris ACE
  • VIN:
    4XADAA322GA599206
  • Location:
    Naples Powersports and Equipment
  • Warranty:
    As Is

BRAKES

  • Front Brake Type:
    Hydraulic Disc
  • Rear Brake Type:
    Hydraulic Disc

DRIVE LINE

  • Differential Lock Location:
    Rear
  • Driveline Brand:
    On-Demand™
  • Driveline Type:
    AWD
  • Limited Slip Differential Location:
    Rear
  • Number Of Driveline Modes:
    2

ENGINE

  • Bore (in):
    3.07
  • Bore (mm):
    78
  • Carburetion Type:
    Fuel Injected
  • Compression Ratio:
    11.5
  • Cooling:
    Liquid
  • Cylinders:
    1
  • Displacement (cc):
    325
  • Displacement (ci):
    19.8
  • Engine Brand Name:
    ProStar™
  • Engine Stroke:
    4-Stroke
  • Engine Type:
    Single-Cylinder
  • Fuel Injector Size (mm):
    36
  • Fuel Injector:
    Yes
  • Fuel Requirements:
    Regular
  • Fuel Type:
    Gas
  • Horsepower (bhp):
    32
  • Horsepower (kW):
    23.9
  • Starter:
    Electric
  • Stroke (in):
    2.68
  • Stroke (mm):
    68
  • Valve Configuration:
    DOHC
  • Valves Per Cylinder:
    4
  • Valves:
    4

EXTERIOR

  • Bash Plate (Front):
    Yes
  • Body Material:
    Composite
  • Frame:
    Steel

INSTRUMENTATION

  • Fuel Level Warning Type:
    Gauge
  • Temperature Warning Type:
    Light

LIGHTS

  • Type:
    Halogen

SEATS

  • Backrest Location:
    Driver
  • Backrest Type:
    Fixed
  • Number Of Seats:
    1
  • Seat Location:
    Driver
  • Seat Material:
    Vinyl
  • Seat Type:
    One-Piece

STEERING

  • Steering Control:
    Steering Wheel
  • Steering Type:
    Manual

STORAGE

  • Bed Height (in):
    4
  • Bed Height (mm):
    100
  • Bed Length (in):
    17
  • Bed Length (mm):
    430
  • Bed Width (in):
    35
  • Bed Width (mm):
    890
  • Capacity (kgs):
    110
  • Capacity (kgs):
    55
  • Capacity (lbs):
    120
  • Capacity (lbs):
    240
  • Cargo Bed Material:
    Polyethylene
  • Rack Rails Location:
    Rear

SUSPENSION

  • Front Suspension Type:
    McPherson Strut
  • Front Travel (in):
    8.2
  • Front Travel (mm):
    208
  • Number Rear Shock Absorbers:
    2
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Stabilizer Bar:
    Yes
  • Rear Suspension Material:
    Steel
  • Rear Suspension Type:
    Independent Double A-Arm
  • Rear Travel (in):
    9.5
  • Rear Travel (mm):
    241

TECHNICAL SPECIFICATIONS

  • Dry Weight (kg):
    377
  • Dry Weight (lbs):
    830
  • Engine Displacement to Weight (cc):
    0.39
  • Fuel Capacity (gal):
    5.3
  • Fuel Capacity (l):
    19.9
  • Ground Clearance (in):
    10.3
  • Ground Clearance (mm):
    260
  • GVWR (kgs):
    660
  • GVWR (lbs):
    1455
  • Height (in):
    68
  • Height (mm):
    1730
  • Length (ft):
    7.5
  • Length (ft/ft):
    7
  • Length (ft/in):
    6
  • Length (in):
    90
  • Length (mm):
    2290
  • Payload Capacity (kgs):
    261
  • Payload Capacity (lbs):
    575
  • Towing Capacity (kgs):
    680.4
  • Towing Capacity (lbs):
    1500
  • Wheelbase (in):
    61.5
  • Wheelbase (mm):
    1562
  • Width (in):
    48
  • Width (mm):
    1220

TOWING & HAULING

  • Rear Hitch Type:
    Receiver
  • Size (cm):
    3.2
  • Size (in):
    1.25
  • Tongue Weight (kgs):
    68
  • Tongue Weight (lbs):
    150

TRANSMISSION

  • Hi / Low Range:
    Yes
  • Primary Drive (Engine / Transmission):
    Belt
  • Primary Drive (Front Wheel):
    Shaft
  • Primary Drive (Rear Wheel):
    Shaft
  • Reverse:
    Yes
  • Transmission Brand:
    Polaris Variable Transmission (PVT)
  • Transmission Type:
    Continuously Variable (CVT)

WHEELS & TIRES

  • Front Tire (Full Spec):
    25 x 8-12
  • Front Tire Diameter (in):
    25
  • Front Tire Width:
    8
  • Front Wheel Diameter:
    12
  • Rear Tire (Full Spec):
    25 x 10-12
  • Rear Tire Diameter (in):
    25
  • Rear Tire Width:
    10
  • Rear Wheel Diameter:
    12
  • Wheels Composition:
    Steel
